Department of Pathology, Seoul National University College of Medicine, Seoul, Korea
© 2015 The Korean Society of Pathologists/The Korean Society for Cytopathology
This is an Open Access article distributed under the terms of the Creative Commons Attribution Non-Commercial License (http://creativecommons.org/licenses/by-nc/3.0/) which permits unrestricted noncommercial use, distribution, and reproduction in any medium, provided the original work is properly cited.
| Cytology diagnosis | Total |
|---|---|
| Ductal adenocarcinoma | 53 |
| Malignant tumor, unspecifi | 28 |
| Neuroendocrine neoplasm | 10 |
| Mucinous neoplasm | 2 |
| Squamous cell carcinoma | 1 |
| Total | 94 |
| Categorya | Case No. | Sex | Age (yr) | Location | Cytology diagnosis | Surgical diagnosis | |
|---|---|---|---|---|---|---|---|
| 1 | False-negative | 1 | F | 70 | Neck | IFD | Ductal adenocarcinoma |
| 2 | F | 53 | Uncinate | IFD | Ductal adenocarcinoma | ||
| 3 | M | 69 | Tail | IFD | Ductal adenocarcinoma | ||
| 4 | F | 65 | Body | IFD | Ductal adenocarcinoma | ||
| 5 | M | 76 | Body | IFD | Ductal adenocarcinoma | ||
| 6 | M | 58 | Head | IFD | Ductal adenocarcinoma | ||
| 7 | M | 77 | Body | IFD | Ductal adenocarcinoma | ||
| 8 | M | 76 | Body | IFD | Ductal adenocarcinoma | ||
| 9 | F | 69 | Neck | IFD | Ductal adenocarcinoma | ||
| 10 | M | 71 | Body | IFD | IPMN | ||
| 11 | F | 70 | Main p-duct | IFD | Malignancy, unspecifi | ||
| 12 | F | 50 | Body | IFD | Neuroendocrine tumor | ||
| 2 | False-positive | 13 | M | 75 | Body | Suspected carcinoma | Negative for tumor |
| 14 | M | 75 | Body | Suspected carcinoma | Negative for tumor | ||
| 15 | M | 60 | Neck | Carcinoma | Negative for tumor | ||
| 16 | F | 58 | Body | Adenocarcinoma | Negative for tumor | ||
| 17 | F | 82 | Head | Atypical | Negative for tumor | ||
| 18 | F | 38 | Body | Atypical | Negative for tumor | ||
| False-negative | 19 | M | 57 | Tail | Negative for tumor | Ductal adenocarcinoma | |
| 20 | F | 61 | Uncinate | Negative for tumor | Ductal adenocarcinoma | ||
| 21 | F | 51 | Tail | Negative for tumor | Ductal adenocarcinoma | ||
| 22 | F | 41 | Head | Negative for tumor | Ductal adenocarcinoma | ||
| 23 | M | 77 | Body | Negative for tumor | Ductal adenocarcinoma | ||
| 24 | F | 67 | Head | Negative for tumor | Ductal adenocarcinoma | ||
| 25 | F | 72 | Head | Negative for tumor | Ductal adenocarcinoma | ||
| 26 | M | 57 | Tail | Negative for tumor | Ductal adenocarcinoma | ||
| 27 | F | 73 | Uncinate | Negative for tumor | Ductal adenocarcinoma | ||
| 28 | M | 64 | Body | Negative for tumor | Ductal adenocarcinoma | ||
| 3 | False-positive | 29 | M | 50 | Body | Atypical | Lymphoplasmocytic sclerosing pancreatitis |
| 30 | F | 60 | Distal part | Atypical | Lymphoplasmocytic sclerosing pancreatitis | ||
| False-negative | 31 | M | 76 | Body | Negative for tumor | Ductal adenocarcinoma | |
| 32 | M | 56 | Head | Negative for tumor | Ductal adenocarcinoma | ||
| 33 | M | 61 | Tail | Negative for tumor | Ductal adenocarcinoma | ||
| 34 | F | 58 | Tail | Negative for tumor | Ductal adenocarcinoma | ||
| 35 | F | 70 | Uncinate | Negative for tumor | IPMN |
F, female; IFD, insufficient for diagnosis; M, male; IPMN, intraductal papillary mucinous neoplasm.
aDiscrepancy category: 1) Insufficient for diagnosis (cytology specimen of too few cells), 2) Technical targeting error (normal parenchyma or other non-lesion area aspirated), and 3) Misdiagnosis by pathologists.
PubReader
ePub Link
Cite this Article
| Cytology diagnosis | Surgical diagnosis | No. of cases | Category | |
|---|---|---|---|---|
| Negative (35 cases, 18.3%) | Non-neoplastic lesion | 15 | True-negative | |
| Benign lesion | 2 | True-negative | ||
| Atypical (undetermined) | 2 | Excluded | ||
| Malignant neoplasm (n=15) | Ductal adenocarcinoma | 13 | False-negative | |
| Neuroendocrine tumor | 1 | |||
| IPMN | 1 | |||
| Benign lesion (5 cases, 2.6%) | TIFD | 1 | Excluded | |
| Non-neoplastic lesion | 0 | True-negative | ||
| Benign lesion | 5 | True-negative | ||
| Atypical (undetermined) | 0 | Excluded | ||
| Malignant neoplasm | 0 | False-negative | ||
| Atypical (undetermined) (37 cases, 19.4%) | TIFD | 0 | Excluded | |
| Non-neoplastic lesion | 4 | False-positive | ||
| Benign lesion | 1 | False-positive | ||
| Atypical (undetermined) | 5 | Excluded | ||
| Malignant neoplasm (n=24) | Ductal adenocarcinoma | 18 | True positive | |
| Neuroendocrine tumor | 2 | |||
| IPMN | 2 | |||
| Malignant tumor, unspecifi | 2 | |||
| Malignant neoplasm (94 cases, 49.2%) | TIFD | 3 | Excluded | |
| Non-neoplastic lesion | 4 | False-positive | ||
| Benign lesion | 0 | False-positive | ||
| Atypical (undetermined) | 9 | Excluded | ||
| Malignant neoplasm (n=79) | Ductal adenocarcinoma | 57 | True-positive | |
| Neuroendocrine tumor | 10 | |||
| Carcinoma | 4 | |||
| IPMN | 3 | |||
| Solid-pseudopapillary neoplasm | 2 | |||
| Mucinous neoplasm | 1 | |||
| Malignant mesenchymal tumor | 1 | |||
| Metastatic leiomyosarcoma | 1 | |||
| Insuffi for diagnosis (20 cases, 10.5%) | TIFD | 2 | Excluded | |
| Non-neoplastic lesion | 5 | True-negative | ||
| Benign lesion | 1 | True-negative | ||
| Atypical (undetermined) | 1 | Excluded | ||
| Malignant neoplasm (n=12) | Ductal adenocarcinoma | 10 | False-negative | |
| IPMN | 1 | |||
| Malignant tumor, unspecifi | 1 | |||
| TIFD | 1 | Excluded | ||
| Total | 191 | |||
| Cytology diagnosis | Total |
|---|---|
| Ductal adenocarcinoma | 53 |
| Malignant tumor, unspecifi | 28 |
| Neuroendocrine neoplasm | 10 |
| Mucinous neoplasm | 2 |
| Squamous cell carcinoma | 1 |
| Total | 94 |
| Category | Percentage | Equation |
|---|---|---|
| TP (103 cases) | 61.7 | N/A |
| TN (28 cases) | 16.8 | N/A |
| FP (9 cases) | 5.4 | N/A |
| FN (27 cases) | 16.1 | N/A |
| Diagnostic accuracy | 78.4 | (TP+TN)/(TP+TN+FP+FN) × 100 |
| Sensitivity | 79.2 | TP/(TP+FN) × 100 |
| Specifi | 75.7 | TN/(TN+FP) × 100 |
| Positive predictive value | 92.0 | TP/(TP+FP) |
| Negative predictive value | 50.9 | TN/(TN+FN) |
| FP rate | 24.3 | FP/(FP+TN) |
| FN rate | 11.6 | FN/(TP+FN) |
| Category |
Case No. | Sex | Age (yr) | Location | Cytology diagnosis | Surgical diagnosis | |
|---|---|---|---|---|---|---|---|
| 1 | False-negative | 1 | F | 70 | Neck | IFD | Ductal adenocarcinoma |
| 2 | F | 53 | Uncinate | IFD | Ductal adenocarcinoma | ||
| 3 | M | 69 | Tail | IFD | Ductal adenocarcinoma | ||
| 4 | F | 65 | Body | IFD | Ductal adenocarcinoma | ||
| 5 | M | 76 | Body | IFD | Ductal adenocarcinoma | ||
| 6 | M | 58 | Head | IFD | Ductal adenocarcinoma | ||
| 7 | M | 77 | Body | IFD | Ductal adenocarcinoma | ||
| 8 | M | 76 | Body | IFD | Ductal adenocarcinoma | ||
| 9 | F | 69 | Neck | IFD | Ductal adenocarcinoma | ||
| 10 | M | 71 | Body | IFD | IPMN | ||
| 11 | F | 70 | Main p-duct | IFD | Malignancy, unspecifi | ||
| 12 | F | 50 | Body | IFD | Neuroendocrine tumor | ||
| 2 | False-positive | 13 | M | 75 | Body | Suspected carcinoma | Negative for tumor |
| 14 | M | 75 | Body | Suspected carcinoma | Negative for tumor | ||
| 15 | M | 60 | Neck | Carcinoma | Negative for tumor | ||
| 16 | F | 58 | Body | Adenocarcinoma | Negative for tumor | ||
| 17 | F | 82 | Head | Atypical | Negative for tumor | ||
| 18 | F | 38 | Body | Atypical | Negative for tumor | ||
| False-negative | 19 | M | 57 | Tail | Negative for tumor | Ductal adenocarcinoma | |
| 20 | F | 61 | Uncinate | Negative for tumor | Ductal adenocarcinoma | ||
| 21 | F | 51 | Tail | Negative for tumor | Ductal adenocarcinoma | ||
| 22 | F | 41 | Head | Negative for tumor | Ductal adenocarcinoma | ||
| 23 | M | 77 | Body | Negative for tumor | Ductal adenocarcinoma | ||
| 24 | F | 67 | Head | Negative for tumor | Ductal adenocarcinoma | ||
| 25 | F | 72 | Head | Negative for tumor | Ductal adenocarcinoma | ||
| 26 | M | 57 | Tail | Negative for tumor | Ductal adenocarcinoma | ||
| 27 | F | 73 | Uncinate | Negative for tumor | Ductal adenocarcinoma | ||
| 28 | M | 64 | Body | Negative for tumor | Ductal adenocarcinoma | ||
| 3 | False-positive | 29 | M | 50 | Body | Atypical | Lymphoplasmocytic sclerosing pancreatitis |
| 30 | F | 60 | Distal part | Atypical | Lymphoplasmocytic sclerosing pancreatitis | ||
| False-negative | 31 | M | 76 | Body | Negative for tumor | Ductal adenocarcinoma | |
| 32 | M | 56 | Head | Negative for tumor | Ductal adenocarcinoma | ||
| 33 | M | 61 | Tail | Negative for tumor | Ductal adenocarcinoma | ||
| 34 | F | 58 | Tail | Negative for tumor | Ductal adenocarcinoma | ||
| 35 | F | 70 | Uncinate | Negative for tumor | IPMN |
TIFD, tissue insufficient for diagnosis; IPMN, intraductal papillary mucinous neoplasm.
TP, true positive; TN, true negative; FP, false positive; FN, false negative; N/A, not applicable. Surgically ‘atypical’ (17 cases) and ‘tissue insufficient for diagnosis’ (7 cases) cases are excluded.
F, female; IFD, insufficient for diagnosis; M, male; IPMN, intraductal papillary mucinous neoplasm. Discrepancy category: 1) Insufficient for diagnosis (cytology specimen of too few cells), 2) Technical targeting error (normal parenchyma or other non-lesion area aspirated), and 3) Misdiagnosis by pathologists.
